Arduino Controlled Relay Module | Home Automation | Tutorial
Показать описание
Mish Mash Labs demonstrate how to control a SRD-05VDC-SL-C 5v Relay Module using an Arduino. This relay can switch devices up to 10 amps at 250VAC using 5v from the Arduino.
We you how to wire the relay, how to write the control program.
We used the DM DIYmore Arduino Nano Clone, but this will work with all Arduinos.
0:51 Wiring Diagram
1:43 Control Side Wiring Explanation/Demonstration
2:44 Code Explanation
3:28 Control Test Demonstration
4:05 High Voltage Side Wiring Explanation/Demonstration (230VAC)
6:00 Full Demonstration
Code on Mish Mash's GIT;
