Bmw F20, Android display install, car without factory display.

BMW F20, 1 series, year 2012, without factory display.
10.25" IPS multimedia display, Android

- The car came without factory display
- After instalation, the display took all car information from CAN

# Junsun for BMW Series 1, F20/F21 (2012 - 2017)
# Ips, 10.25", Android 11, 4gb ram/ 64gb storage, wifi, bluetooth, 4g sim card, DSP, Carplay, AndroidAuto, 2xUSB...etc.

It took 2 days for installing because i had some issues with backup camera wich only worked for first time when it was in reverse and after a few minutes it was showing no signal but i figured out finally what was the problem :), also, because the car came without brackets under the dash for fixing the display, i had to invent something wich is not showed in the video :)
If you have any questions, feel free to ask them here or email me and i will gladly help.

Later edit:
I can't find the blueprint wich i made when i installed this unit, because a lots of people asked, i lost it somewhere when i cleand my repair shop but it is very easy to make your own. I just put a piece of paper on the dashboard where the unit will be installed, then draw the outline margins of it with a pen. After doing this i compared it with the display bottom and made the drawings and final measurements (measure 10 times, cut once :) )
As i made my own research, this aftermarket units are slightly different in design from one to another and they do not have the same length, height or width.

Thank you,
Enjoy
Mike
-----------------------------------------------------------------------------------------------

Track: Jim Yosef - Samurai [NCS Release]
Music provided by NoCopyrightSounds.

[incartechie]

Great video - we also fit the same upgrade over here in the UK!

[Tk-euih]

Hey! I saw your video about installing a screen in a BMW F22 that originally didn’t have a display. I’m thinking of doing the same. Does this work with any aftermarket screen that supports Apple CarPlay and Android Auto? Or do I need a specific kit or any other extra parts besides cutting the hole for the screen? Thanks!

[MaxiYP]

I wanted to ask you two questions. The steering wheel isn't the one that came standard, right? I bought a steering wheel with buttons, and now I want to buy the screen. Do all the buttons work? Thank you very much.

[ibrahimbelhadj]

Hi, is there a video about the wiring? Thanks

[jonasweinert]

Great Video! Was the wiring complicated? I'm not that good at it, can a beginner do it?

[joseluisarroyoaycart]

For the theme of sound. Do you have to change anything in the cables? Or is it plug and play?

[lilonizuka]

ciao vorrei sapere come avete fatto con il cablaggio sarei curioso?

[jenssnoeckpieters]

I have a question, which cables do you use for the screen and if you buy the screen for f20, everything is already included

[avarangemusic]

Hello, i just bought this head unit and I don’t have idrive From factory also (in my F20). Is there any chance to send me this blueprint with PDF or something ? Your fitment is perfect🥲

[kasuakonrad]

Hello, version with which connector to choose to fit car without factory display?

[Shark_WFace]

hi, I also installed an android unit on my f20 without screen and idrive but I can't see the car data as you say via canbus. did you make any particular connections? the unit works perfectly but I can't see only the vehicle data. can you help me please? Thank you.

[christosstambelos]

Hello I would like to ask where to get the blueprint

[pinoshdronzone]

hi, I mounted an android monitor on my 1 series without original monitor but I have a problem. I connect with bluetooth and I only hear the audio of the calls and not the audio of the songs. This also happens with the usb stick. The media on the phone pauses and there is no audio.

[deividascereska]

Hey can you send me the infomration in centimeters or inches how to make that plastic thing, because I don’t know the measures, thank you so much, I have the same model

[PhoEniX-ipxn]

Hello, i have few questions about installation, can I contact with you in a private chat?

[joseluisarroyoaycart]

Could you say what cut-off measures are they? Thxs!!

[jishanahmed]

Hi, I dont have any NBT port. Would you build this Display without NBT port?

[jenssnoeckpieters]

I have a problem, I connected the screen to try first and got no sound and then I tried playing music via aux with my phone and it didn't work either. Then I connected the original radio with the wiring in between and the aux worked again, help

[stef]

Salut, unde putem sa vorbim in privat pentru cateva detalii ?

[joselegomez]

Dejame el enlace porfavor de la pantalla que compraste
