Verisurf 2022 - Feature Highlights | Enhanced Data Extraction

Verisurf 2022 expands the functionality of group-alignment and CAD-based extraction through the use of a pre-selection filter for scan data. Pre-selection enables more complex extraction strategies by allowing the main selection to operate on subsets of the scan data, and it improves extraction efficiency by processing only the required data. Pre-selection is used with Group-Alignment to first filter the scan data based on proximity to the pre-selection CAD entities, such as datum-targets. This subset is then registered to the main selection, such as CAD surfaces. Using two-stage selection, in this case, enables automation of non-contact, three-two-one alignment prior to feature extraction. Pre-selection can also be used to filter the CAD extraction zone prior to fitting or analysis. For example, section planes can be used to pre-select profiles from the scan data. These profiles are then compared to the main CAD selection as an analysis. Here, two-stage selection enables the automation of line or surface-profile in a single operation.

✅ Pre-filter data using CAD entities
✅ Enables multi-step alignment and extraction
✅ Automates cross-section analysis

👍Click the like-button on all new videos.
🔔Turn on notifications for new videos!

00:00 Introduction
00:10 Scan Data Filters
00:20 Pre-selection For Efficiency
00:30 Proximity To Features
00:40 Automation of Alignments
00:50 Define Sections For Analysis
01:00 Fast Profile Display
01:10 Schedule A Demonstration
01:20 Watch More Videos And Subscribe

#verisurf2022 #manufacturing #cmmprogramming
