Creo Parametric - Middle Out Design | Assembly Modeling

This Creo Parametric tutorial video shows the Middle Out Design method, which combines Bottom Up and Top Down techniques. Middle Out is commonly used when packaging around a number of COTS (Commercial Off The Shelf) components or legacy components that already exist. After these components are placed in an assembly, structural subassemblies are created with Skeletons and Data Sharing Features to reference the existing components.

If you learned something from this video, please give it a thumbs up. If you like this video, please click the Subscribe button to be informed when new videos are uploaded. Also please write a comment if you would like to see more videos like this.

Feel free to share or embed this video, and add it to your playlists.

Creo admins, you can share the Creo Parametric channel with your users as a training tool:

Thanks,
Dave

[DanielKuoma]

Hello! I am an avionics designer and your videos were very helpful to me, thank you!

[gasmimohamedbaha]

I really like this technique a lot. I've never heard of it before but it looks like it has some significant use in cabling applications and mechanical structures for mechatronics systems. Thank you Dave for this great video

[RnioBB]

This is the area that currently i'm working with, with out knowing how to call this method thus i thank for this video.I have the habit to use copy geometry more often and in situations that is not the preferable option, due to limited time which results in lack of concentration. So this was a good reminder to take the time and think twice before every step. I'm very much looking forward to watch the continuation of this series.
