Optical Flow with Arduino Nano

preview_player
Показать описание
A simple Optical Flow Sensor is implemented with the Arduino Nano and ten CdS Photoresistors.
All the signals are read in the analog input A0.
Only two Cds are connected to VCC and GND respectively in each data capture.
Digital pins are used as VCC, GND and as High Impedance (as input).

Based in the work of Geoffrey L. Barrows, Centeye, Inc.
Simple optical flow sensor using 18 CdS cells.

Music by Eirik Trøen Brunvoll
River Flows in You - House/Electro Remix
