DWIN Tutorial: RS485, RS232,TTL connection way for DWIN Smart LCD display----from DWIN Technology

preview_player
Показать описание
DWIN Smart LCD display has the TTL, RS232, RS485 interface, also have 8pin2.0mm, 10pin1.0mm,8pin2.54mm socket. You may have a better understanding for how to connect the display with the adapter, also MCU.

Welcome to contact us if any questions as below:
Whatsapp:8615127618011

Have a nice day~
