#AU-EG#GE3251 #PROJECTION OF LINE Au question and answer solved

2.a) A line AB measuring 75 mm long has one of its ends 50 mm in front of VP and 15 mm above HP. the top view of the line is 50 mm long. draw and measure the front view the other end is 15 mm in front of VP and is above HP. Determine the true inclinations and traces. (APR/MAY 2022 FN)

[priyadharshini-wnpm]

The midpoint of a line AB 75 mm long is 25 mm above HP and 40mm infront of VP. It is inclined at 30° to
HP and 50° to VP. Draw the projection. Determine
the apparent inclinations of line AB

[mohankishor]

Sir au means anna university or annamalai university
