The NEW Hobbywing Max5G2 12S and 650kv/800kv/1100kv g2 motor!

Max5G2 Specs:
The Hobbywing EZRun MAX5 G2 1/5 Scale Waterproof Brushless ESC is a 12S capable ESC designed for 1/5 scale power! The MAX5 provides the ultimate power upgrade solution for many popular 1/5 scale vehicles like the HPI Baja Buggy, Losi 5IVE-T Nitro-to-Electric Truck, and Desert Buggy XL Nitro-to-Electric buggy. It is also suitable for various other brands of 1/5 scale on-road cars, buggies, and truggies. The strong explosive, stable output power, together with excellent low-speed linearity, ensures the ESC meets various application requirements such as; violent start-up, straight-line high-speed, flying slopes, low-speed walking, etc.

NOTE: For peak performance, it is recommended to pair this ESC to the Hobbywing EzRun 56118 SD G2 Motors.

Features:
Enhanced Performance: The ESC supports up to 12s Lipo with a maximum output current of up to 250A.
Intelligent Freewheeling Technology: The innovative intelligent freewheeling technology effectively reduces heat generation and enables the ESC to have higher driving efficiency.
Turbo Timing Technology: The ESC is able to support up to 24 degrees of Turbo Timing adjustment.

Continuous Current: 250A
Peak Current: 1,600A
Motor Type: Sensored / Sensorless Brushless Motor (only in sensorless mode)
Applications: 1/5th Touring Car, Buggy, Truggy, and Truck
LiPo/NiMH Cells: 6-12S LiPo
BEC Output: 6V/7.2V/8.4V Switchable, Continuous Current of 8A (Switch-mode)
Connectors: Input End: None, Output End: Female 8.0mm Gold Connectors (pre-soldered onto the PCB of the speed controller)
Size (LxWxH): 94.5x59.4x50.9mm
Weight: 428.5g
Programming Port: Independent Programming Port

56118 Motor Specs ALL KV's
The Hobbywing EZRUN 56118SD G2 4-Pole 1/5 Scale Brushless Motor is a monster designed to deliver extreme power with higher efficiency. This dust and waterproof motor will be a great option for 1/5 vehicles. Package includes one brushless motor.

Features:
4-pole rotor design for more torque with strong explosive force
Detachable motor design for easy maintenace
Waterproof sensor interface
Explosion proof rotors
Spiral CNC shell

Specifications: 650kv
Input Voltage: 8-12S LiPo
KV: 650kV
Pole: 4
Motor Diameter: 2.20" (56mm)
Motor Length: 4.69" (119.2mm)
Shaft Diameter: 0.31" (8mm)
Shaft Length: 1.18" (30mm)
Front Bearing size: D22*D8*T7
Rear Bearing size: D19*D5*T6
Weight: 1272g

Specifications: 800kv
Input Voltage: 8-12S LiPo
KV: 800kV
Pole: 4
Motor Diameter: 2.20" (56mm)
Motor Length: 4.69" (119.2mm)
Shaft Diameter: 0.31" (8mm)
Shaft Length: 1.18" (30mm)
Front Bearing size: D22*D8*T7
Rear Bearing size: D19*D5*T6
Weight: 1277g

Specifications: 1100kv
Input Voltage: 6-8S LiPo
KV: 1100kV
Pole: 4
Motor Diameter: 2.20" (56mm)
Motor Length: 4.69" (119.2mm)
Shaft Diameter: 0.31" (8mm)
Shaft Length: 1.18" (30mm)
Front Bearing size: D22*D8*T7
Rear Bearing size: D19*D5*T6
Weight: 1287g

Get Upside, I use this every time I fill up and just let it earn and fro till Christmas time and cash out. It works and once you get used to it, it’s an easy habit.

#max5g2 #hobbywing #12s

[paulrakis]

Wow those max 5 G2 look beautiful. I sold my new max 5 G1 and 1100KV to get this stuff. Yeah good luck with that 800KV I hope it fits in the kraton well 👍. Try the 1100KV first I know they fit much better and those really need 1100KV from my experience. But yeah you got more wight in her so I get it.

[Addicted_RC]

I asked my local shop to bring one of these in last week for me. I’m really hoping it’s there today. This looks like a great upgrade over the V1 Max 5!!! I still can’t believe they made the Max 5 12s capable and 250 continuous amps! Great detailed review Joe. I can’t wait to see this running! That Kraton is going to be crazy!!! 👊👊👍👍

[buysncharge]

I just bought the older one... I mean it's sweet. But clearly I want this now. And I guess something to put it in.

[KurtsRCs]

That Max5 is going to be crazy. The Kraton looks sick

[tyki_exe]

Looks like I'm building a 12s limitless!

[lordharr]

I would love to see this system in an X-maxx or XRT AND ON 12S SPEED RUNS

[inuyasha]

will that run a 70 120 size motor at 680 kv?

[RDEnduro]

The amp rating is just wild, hopefully just for fractions of a second! I mean it must be quick or those wires would glow red, ,

[odaytim]

Thank you as always for your content . I ordered a max 4 and then the max 5G2 due too the $$ and size for weight saving in my K8S

[brentwhaley]

I’m putting one in my scx6 with the 650kv. Just waiting for it to come in to see what all needs to be done

[jeffdavis]

I've been running the 56118 1100kv on the max6 g2 with no problems so far in my Kraton 8s

[gsxrfun]

Quick ? Buddy I’m running an hobbywing 800kv sensor less with a max 5. I’m thinking about grabbing this new max 5 g2 I wonder if I’ll noticed a difference or not vs the older max 5 you think?

[mikerr]

Exo..as always your nailing it with the content. I can't wait to see it in the k8s as I may be putting that in my k8s depending on your test.

[thatsmyrc]

So the max5 and the 800kv motors does 12s? I thought it would only do 8s? I’m looking for what to instal for my Losi 5t conversion.

[ryanrodriguez]

I’m like the only person that had two new g2 catch on fire in my Kratin 6s. Hobby wing replaced the first one and then that one caught on fire. Idkn why I’m having such bad luck with the g2 esc

[gabibranet]

hello, can you help me too, please, I don't know what's wrong with the controller that doesn't start, I followed all the steps, I have a sensored HOBBYWING EZRUN MAX5

[Ghostin-fstr]

I’m looking at building at 5ive T 2.0 (mainly 8s) will run a lot of 12 also though. Looking to achieve at least 75mph. Is this the way to go or should I go a different direction?

[RobcadRadDad]

Which motors would you recommend for the Xmaxx and Kraton 8s? I was thinking 800kv but everyone seems to go with 1100 for speed? I s the 800kv not fast enough?

[tbrickrc]

Just bought the 1100kv Combo and hope to try 800kv at a later date on my outcast 8s

[kel]

It probably has a higher resolution encoder.
