How to inscribe a Fiber Bragg Grating?

preview_player
Показать описание
In our Photonics lab at the Institute of Microwaves and Photonics (LHFT) we are able to inscribe our own Fiber Bragg Gratings (FBG) using an Excimer laser and the phase mask method. In this video, we would like to invite you to our lab und teach you the basics of the inscription process.
  1. Institute of Microwaves and Photonics (LHFT)
  2. Photonics
  3. Fiber Bragg Grating
  4. Excimer
  5. Laser
  6. Phase Mask
