1-58 AiM Sports PDM Update #2 - Live Webinar with Fabrizio Rizzi - 10/15/2020

In this live webinar, Fabrizio Rizzi (AiM Sportline Hardware Team Manager) and Roger Caddell of AiM Sports review some PDM (Power Distribution Module) basics and then discuss the 6in and 10in Remote Display options as well as the external camera options. Inputs (RIO Module, Blink Marine Keypads) and examples of how to configure these items in Race Studio 3 all while while taking questions from the live webinar attendees.

Presentation:

QandA from today's webinar:

Previous Webinar "Introducing The Aim Sports PDM":

AiM Sports PDM Web Page:

PDM32 User Manual:

PDM08 User Manual:

PDM32 Technical Sheet:

PDM08 Technical Sheet:

PDM Dash 6inch Technical Sheet:

PDM Dash 10inch Technical Sheet:

PDM32/PDM08 Product Brochure:

Video Timestamps
0:00 Opening
2:03 Fabrizio Rizzi Intro
6:00 PDM vs. Relay-Fuse Box
10:40 Future PDM for Existing AiM Systems
12:15 More Than A PDM
14:28 PDM Features
21:23 PDM Output Types
25:00 Poll on Live Attendees Planned PDM Installations
26:00 Remote Display Cable
28:04 Planned PDM Install Poll Results
28:59 6 Inch Remote Display
31:22 10 Inch Remote Display
33:23 Multiple Displays
34:28 Camera Inputs
36:09 Rear View Camera and Data Display Together on the 10 Inch Remote Display
36:40 Remote Keypads
38:11 RIO Module
40:25 RIO Module Configuration in RS3
43:58 Blink Marine Keypad Configuration in RS3
45:23 PDM Input Configuration - Analog Settings
46:56 PDM Input Configuration - Digital Settings
48:25 PDM Input Configuration - Speed Input Settings
53:53 Next Webinar
55:38 Closing
