LIN Controlled Alternator Repair Secrets Revealed

In this video I explain how to use an oscilloscope to diagnose LIN-BUS on charging system. On this Ford Fiesta, alternator is controlled by ECM through LIN (Local Interconnect Network). In this video I show you how I read the LIN BUS waveform and how to analyze it to find a fault on this network. I used a Launch Scopebox on this video.
~~~~~~~~~~~~~~~~~~~~~~~~
