Sliding mesh approach for the large eddy simulation of turbomachinary flow

preview_player
Показать описание
This demo computation illustrates the impact of the turbulent wake generated by moving cylinders on a cascade of turbines (T106A). The Reynolds number based on the isentropic exit condition and the chord is 60,000 with an exit Mach of 0.4. The movie shows the iso-surfaces of the Q-criteria colored by the Mach number.
  1. ZJ Wang
  2. LES
  3. Sliding Mesh
  4. Turbine
  5. CFD
  6. High order methods
