This video shows gold nanoparticles at 600 C. The video shows the stability of the Protochips Fusion™ at high temperatures and the ability to resolve dynamic events with sub-Angstrom resolution. The initial video was taken at 1 frame per second, and then sped up to 5 frames per second using video editing software later. The video was taken in the TEAM 0.5 microscope (FEI Titan, 300 kV, Cs aberration correction, monochromator) at Berkeley National Laboratory, Berkeley, California.
  1. Protochips
  2. Electron Microscope
  3. Protochips
  4. Fusion
