Timecodes:
00:00​ - Intro
00:06​ - What does a vacuum suction cup do?
00:13​ - Vacuum suction cup materials
00:24​ - How a vacuum suction cup works
01:06​ - Calculating vacuum suction force
01:32 - Flat vacuum suction cup
02:04 - Oval vacuum suction cup
02:17 - Bellows-type vacuum suction cup
02:32​ - Outro
-------------------------------------
Links in this video:
-------------------------------------
Tameson is your online specialist for fluid control. On our website, you will find very clear information and tools to directly order the right product for your application. We have over 15,000 products in stock with new product types and variants added on a continual basis. Solenoid valves, ball valves, pneumatic cylinders, hoses, fittings, etc. you name it we have it or can get it. Our engineering support team and global delivery options allow for new and existing customers (B2B & B2C) to get the right product(s) at the right cost.

VISIT OUR WEBSITE:

FOLLOW US ON SOCIAL MEDIA:

TAMESON NEWSLETTER SUBSCRIPTION
It is straight forward, no nonsense, and full of relevant information about the fluid control industry once a month. We have new product announcements, technical articles, special pricing, and much more that you'll have to subscribe to see!

-------------------------------------------
They are available in different sizes and designs with different suction power capabilities.
A suction cup consists of two parts; the suction cup, which is in direct connection with the product, and the connecting element, a gripping body to which several suction cups are often attached. The suction is usually generated by means of a vacuum generator, also called a vacuum ejector. This is mounted as close as possible to the suction cups. A vacuum generator typically works with compressed air. A venturi tube in the generator creates a vacuum. The vacuum causes the suction cup to stick to the product. The suction cup is completely airtight so that a vacuum is efficiently achieved. As the pressure difference increases, so does the suction power of the suction cup.

The suction force is calculated by multiplying the pressure difference between atmospheric pressure and the pressure inside the cup by the area of the suction cup. The technical article on our website provides a detailed explanation on selecting the correct diameter of the suction cup based on the type of movement it will be doing.

There are different types of suction cups for different applications. For products with a flat or slightly curved surface, flat suction cups are preferred. These suction cups are recommended for universal use and offer good stability due to their flat shape. The flat shape makes them suitable for glass, metal, and cardboard.
-------------------------------------------
