{1093} Delta SMPS not turning ON, DC capacitor and PFC failure

In this video number {1093} Delta SMPS not turning ON, DC capacitor and PFC failure. I explained how to repair delta electronics PMC-24V300W1BA 24 volt 12.5 ampere EOE13010225 switching power supply. i demonstrated fault finding smps step by step. i detected T6.3AH250V, Rubycon 450 volt, 270 microfarad 105 degree centigrade polarized capacitor. i restored its PFC section and power supply started working normally

you can send financial support to this channel;-
Account IBAN;- PK94 HABB 0008 4779 0028 4403
Title; MUHAMMAD ASHRAF
Swift code; HABBPKKA / HABBPKKA007
Habib Bank Limited, Chowk Azam, Pakistan

You are Invited to Join Haseeb Electronics

Please check other videos

You can Follow me on :-

#restoration #tutorial #electronics
00:00 how to repair, no output volatge
01:46 how to disassemble delta electronics smps
04:09 step by step smps repair and troubleshooting
07:40 smooting capacitor heatup
12:00 how to test polar capacitor / polarised capacitor / dc capacitor using digital multimeter
12:32 how to connect bussmann 1 ampere bus fuse wire
13:00 how to test input resistance / input impedance of a circuit
13:13 how to test bridge rectifer in circuit using digital multimeter
14:18 how to test diode rectifier in circuit using multimeter
14:47 how to test mosfet in circuit using multimeter
16:55 20N60C3 mosfet testing with multimeter
22:00 how to check power MOSFET using digital multimeter
25:00 how to troubleshoot smps step by step to repair pfc section
