Z-Transform Pole-Zero Cancellation - Z-Transform Part 1

preview_player
Показать описание

Several of the previous videos that discussed the Z-Transform mentioned the phenomena of "pole/zero cancellation". When this happens, the ROC can actually grow larger.

This video works an example that demonstrates this phenomena. We start with a finite-length signal that consists of the sum of two parts. Since the signal is finite-length we know the ROC must be the entire complex plan except for possibly z = 0 or z = inf.

We show how these two parts when added together result in a pole-zero cancellation, and a resulting ROC that is indeed to majority of the complex plane.

The next video in this playlist is:

The previous video in this playlist is:

Course website:

  1. Adam Panagos
  2. Z-transform
  3. Pole–zero Plot
  4. Region of convergence
  5. ROC
  6. Pole-zero cancellation
