14 Band Spectrum Analyzer Part.1 | Tutorial using Arduino & WS2812

This spectrum analyzers is not two 7 band analyzer operating in stereo. This is a true 14 band analyzers, with accurate frequencies beginning from 40Hz to 16KHz.
This project uses the Arduino Mega 2560 because it has a large enough memory and better performance.
Si5351mcu boards are used for programming masterclock IC frequencies (MSGEQ7).
The Si5351mcu library is needed for this programming.
Special thanks to Pavel Milanes for his outstanding work.

The MSGEQ7 IC is very rare because of limited stock and many sellers sell it but cannot work. if you are having trouble getting an msgeq7 ic you can contact our seller. We guarantee the MSGEQ7 IC can work well.

Thanks all for watching.
Part.2 video
DMS308 board 14 bands spectrum analyzer

WhatsApp [phone]

Shcematic and more :

Full version code in the description of this video

Update your WINRAR before opening.
If you have any questions please comment...

SI5351 board :

Track: Universal by Vibe Tracks

Track: NaNa & Marin Hoxha - OK

[BooBar]
