AuDIT Gold Plating Detection Technology | Thermo Scientific

With the volatility and high price of gold, precious metals, and gems, you cannot afford the time or the potential inaccuracies of traditional testing methods to determine the value of items being bought, sold, or recycled. Using Thermo Scientific portable x-ray fluorescence (XRF) analyzers, now with Thermo Scientific AuDIT gold-plating detection technology, you can find out in just a few seconds, with fire assay-comparable accuracy, the exact precious metal content in jewelry, gold, coins, and other valuable products.

[FieldSafetyInstruments]

Regarding the test stand, yes, it is included with the purchase of the analyzer as a part of the standard package. If you would be using this analyzer in a retail environment, you may also want to have a look at our Niton DXL desktop precious metal analyzer (see youtube video)

[FieldSafetyInstruments]

The simplest testing of a gold bar that is suspected counterfeit (eg gold-cladded tungsten) would be: drill small hole, analyze collected drillings. This will indicate if interior is different material. You would know very quickly – without even the need for analysis, if the interior of the bar is tungsten. Gold is very soft and easy to drill, tungsten is extremely hard and difficult to drill through. The bit would quickly penetrate the gold layer and stop cold when it hits the tungsten.

[fkirsch]

Hello. We bought a Niton XL2 for our business a few months ago but it looks like we don't have the audit technology. Is it possible to have it just by updating the software?

[FieldSafetyInstruments]

The Niton XL2 will provide the composition and gold karat value for any type of sample, including gold bar. It is, however, a surface measurement, so will not provide any information about what is in the center. To get an accurate measurement of the entire bar, one would drill a small hole entirely through the bar, collect the drillings and use the analyzer to test the drillings. This will give an indication as to whether the interior composition is the same as the surface composition.

[earthygreen]

That's exactly what I was thinking. Is there tech out there that can detect thick layers or is that tech too far into the future at the moment? I have a feeling our future will be dealing more directly with gold and less with notes as money.

Small metallic items would work great for this, but inevitably large purchases or transfers will require bars. Thanks for whatever info you have. I found this video really interesting!

[yiawliangchan]

Hi, I am kelvin from malaysia.May I know how fast the device to use for auditing plated gold. The detection device only able to detect if the surface is flatten? How about like those gold necklace and jewellery.it have variety of shape.would it hardly to detect? Since you said it cant penetrate too thick plated gold, may I know how many mm or lesser can it penetrate thru.we are doing pawn shop business.nowadays too much counterfeited gold. Thanks

[FieldSafetyInstruments]

kingevil09 has made a comment on AuDIT Gold Plating Detection Technology | Thermo Scientific

Hi can this thing can detect Gold bar. 12kg? when we buy this product does the package comes with the stand and software or its a different package?
thanks

[FieldSafetyInstruments]

For the most part, yes AuDIT technology will detect gold plated tungsten. However, if you are referring to the recent scandal in NYC where gold bars were found to have tungsten slugs imbedded within, AuDIT will not be able to detect these frauds. The gold layer is much too thick for XRF to penetrate the surface and see the tungsten embedded inside.

[FieldSafetyInstruments]

The sample does not need to be flat; shape of the sample does not matter – it can easily be used to test chains, links etc. The penetration depth through gold plate is about 8 – 10 microns. Typical decorative gold plating is less than 3 microns. The only items that create issues for AuDIT are items that are cladded or “Gold filled” as these are not actually plated materials, but are cladded with a relatively thick layer of gold.

[markseneris]

Hi I would like to know if this product can also determine the gold classification i.e. to 10k, 18, 21k etc.? thanks!

[marlenegasdia]

“Mr. Kirsch, Thank you for your comments and your interest in our latest products. The answer depends on the version of operating system software you are running. If you are running version 8.0A or later on your analyzer, then we can do the upgrade in the field via email FREE OF CHARGE.”.
If you have an analyzer running an older version than this e.g. 7.X, we will arrange for your analyzer to be returned to the factory for the upgrade....continued

[thevillaman]

Hi where can i buy one and how much ps good video
