IPS (AH) vs PLS monitor comparison | Benq VZ2350HM Review

In this video, I will review the 23 inch benq vz2350hm flicker free ah-ips monitor and simultaneously compare side by side with a pls panel monitor , with respect to color quality, viewing angles and gaming performance.
ips monitor vs pls monitor comparison

To buy

BenQ VZ 2350 HM flicker free monitor Specifications

Screen Size: 23 inches
Backlight : LED
Resolution:1080P FHD (Full HD monitor) 1920x1080
Pixel Pitch (mm)‎ 0.265‎
Aspect Ratio: 16:9
Panel Technology: AH-IPS (Advanced High performance - In Plane Switching)
Display Colors:‎ 16.7million‎
Color Gamut : 72% of NTSC
Refresh Rate: 60Hz
Response Time: 5 ms GTG (Grey To Grey) 14 ms (Black To White)
Contrast Ratio: 1000:1 Native
DCR (Dynamic Contrast Ratio) (typ.)‎ 20M:1
Brightness: 250 cd/m²
Feature : Flicker free, frameless slim Narrow Bezel, 178/178 Viewing angles
Built-in Speakers: yes Stereo
Stand: Height – Yes (3.6 Inches)
Stand: Tilt – Yes 0-20
VESA Compatibility: Yes (100 x 100)
Connectivity: HDMI x 1, VGA x 1,DVI-D, 3.5mm Audio Jack
Powe supply : Built in
Power consumption : 35 watts
Power saving mode : 0.5W
Weight : 4KG
OS : Windows 7, Windows 8, 8.1, Windows 10

Samsung SE390/LS27E390HS PLS monitor specification

Display Screen Size 27"
Active Display Size (HxV) 597.9mm(H)x336.3mm(V)
Aspect Ratio 16:9
Panel Type PLS
Brightness (Typical) 300cd/m2
Brightness (Min) 240cd/m2
Contrast Ratio Static 1000:1(Typ), 700:1(Min)
Dynamic Contrast Ratio
Mega DCR Resolution 1920x1080
Pixel Pitch (HxV) 0.3114mm(H)x0.3114mm(V)
Response Time 4(GTG)
Viewing Angle (H/V) 178°/178°
Color Support 16.7M colors
General Feature
Samsung MagicBright
Yes
Samsung MagicUpscale
Yes
Eco Saving Plus
Yes
Eye Saver Mode
Yes
Flicker Free
Yes
Game Mode
Yes
Image Size
Yes
OS Compatibility
Windows, Mac
Windows Certification
Windows 8.1
Interface
D-Sub
1 EA
HDMI
1 EA
Headphone
1 EA
Operation Conditions
Temperature (℃)
10℃~40 ℃
Humidity (%)
10~80 (non-condensing)
Design
Color+
Black High Glossy
Stand Type Simple Tilt
-2°（±2°）to15°（±2°）
Eco
Energy/Environment Mark
Energystar6.0
PVC Free (Accessory Cables Excluded)
Yes
Power
Power Supply
AC 100~240V
Power Consumption (Max)
29 W
Power Consumption (Typ)
25 W
Power Consumption (DPMS)
0.3(Typ.)
Power Type External Adaptor

vmreviews

[Shadow]

They look almost the same but the pls gave better darks

[shubhkarman]

Really good review with lots of detail that everybody must know before buying this monitor. Keep up the good work mate !

[knabellaks]

Great help! In-depth comparison was great. A great video visually also!

[quirinstark]

Just want to say thanks for your monitor reviews. Been looking at them for quite a while.

[reza-edil]

good review among all the crappy reviews for monitors

[lennonleonardo]

I am choosing between BenQ RL2455HM and BenQ VZ2350HM. But obviously the first one is more expensive. Good review, I'm definitely getting this model. Thanks!

[mrfarazi]

finally I bought this monitor under your recommendation, overall it's more than ok to me but my unit doesn't have a good calibration at all. can you recommend your unit calibration to me please? the calibration in your review looks good.
another question I have: did you measure its color gamut? I feel it is a bit short.

[SparKcod]

Can u please answer my question? How is the sound of the ah-ips monitor? Is it good? Loud? Clear?

[MrThegreymatter]

Very helpful review. Thank you for sharing.
Sir kindly help me by suggesting which one to go for. I am in a dilemma on which one to buy between GW2470H and VZ2350HM.

[mrfarazi]

good review from my favorite reviewer, is it so wobbly? I'm a programmer and I type a lot so it's important for me it doesn't wobble while I'm typing with keyboard. another question: I'm wondering between this model and gw2270hm which one is better? my use is programming, watching movies and a bit gaming

[Edgars]

Hmm, PLS looks better or IPS monitor is under angle.

[richie]

nice video but is there a difference between LED IPS and AH IPS? I have an Asus Full HD LED IPS and an Acer 144 Hz WQHD AH IPS...

[TheDog]

What type Panel is best for gaming High Colour Gamut PLS/IPS/VA or TN?

[DomeNir]

good review conclude Which color is best?

[soumyabiswas]

Low blue light filter Kya color calibration karke la sakte and eye Care mode vi Kya color calibration karke la sakte

[uvaissss]

Waiting for G4600 hd630 based gaming review.. Also plz use all setting lower + ~720p resolution... I want good fps

[riegin]

may i know what settings youre using red, green, blue, contrast and brightness.. thanks

[soumyabiswas]

Best 22 inch monitor batw
I use to play nfs bf crysis doom which monitor will be better

[CaptainScorpio]

Excellent dude :)
Can yuh help in selecting an ips monitor from Lg 20mp28hb, benq vz2250h, acer r221q and aoc 2279vm.
I am from india

[singhj]

thank u for this useful info..i just want dual setup monitor for normal using please suggest can i setup Benq 23 (BenQ VZ 2350 HM) and 27 (BenQ EW 2775 ZH ) monitor (FOR MOVIES AND VIDEO) or just go with both monitor the same size....
currently i using sony led tv 32 and aoc 20 inch lcd monitor....
