Setting Up LDAP Authenticated Directory in Apache HTTPD

#PHP #ApacheHTTPD #ActiveDirectory #LDAP

In this quick video learn how to setup LDAP/Active Directory authentication on an Apache webserver to secure web based applications.

--------------------------------------------------------------------
Active Directory Setup
--------------------------------------------------------------------
   01. Open Active Directory Users and Computers
   02. Expand the domain ≫ Users
   03. Right Click Users ≫ New ≫ User
   04. Create a read only account to use for LDAP binding
    First Name: Read
    Last Name: Only
    User logon name: readonly_svc
   05. Click Next
   06. Set the user's password and confirm it
   07. Uncheck User must change password on next logon
   08. Check User cannot change password
   09. Check Password never expires
   10. Click Next
   11. Click Finish
   12. Right Click Users ≫ New ≫ Group
   13. Give the group a name and click OK
   14. Right Click the newly created group ≫ Properties
   15. Select the Members tab ≫ Click Add...
   16. Add users that will be allowed access to the web application
   17. Click OK

--------------------------------------------------------------------
Configuring Apache HTTPD for LDAP
--------------------------------------------------------------------
   01. Navigate to the Apache install directory/conf in Explorer
   03. Find the authnz_ldap_module and make sure it is enabled by removing the # at the start of the line
   04. Find the ldap_module and make sure it is enabled by removing the # at the start of the line
   05. Create a Location block to enable LDAP authentication for the specified directory
         ≪location /ldaptest≫
         # Basic authentication with LDAP against MS AD
         AuthType Basic
         AuthBasicProvider ldap
         # AuthLDAPURL specifies the LDAP server IP, port, base DN, scope and filter
         # using this format: ldap://host:port/basedn?attribute?scope?filter
         # The LDAP bind username and password
         AuthLDAPBindPassword "Read0nly!!"
         LDAPReferrals Off
         AuthUserFile /dev/null
         # to authenticate a domain group, specify the full DN
         AuthLDAPGroupAttributeIsDN on
         require ldap-group CN=WebAuthAccess,CN=Users,DC=i12bretro,DC=local
         ≪/location≫
   07. Restart the Apache service
   08. Open a browser and navigate to the LDAP authenticated URL
   09. An authentication prompt should appear, allowing only users in the AD group specified access


### Connect with me and others ###

[-NmLss--Fr-]

nice Video! Just a short question: i need to do the same with more than two different AuthLDAP-URLs, to query two different OUs in which the Users are stored. I have tried with <AuthnProviderAlias>, but apache throw me an "<AuthnProviderAlias not allowed here" error in the apache error log :( . Maybe you can give me a hint?

[vjzp]

You did not use the username that you created on AD to log in the webpage.
