3D Printed Robot Arm

This is a 3D printed robot arm. Credit to the design goes to Jeff Kerr, who goes by LoboCNC on Thingiverse. I show how to assemble the actuators since they are the most detailed part of the build. I will be running ESP32's in each joint so I can control each joint via Bluetooth/Wifi so I only need to run 2 wires to each joint for power. ChiliPeppr and Serial Port JSON Server will be used to control the arm once all the code is written.

Chilipeppr ESP32 for Lua Workspace where I'm writing the code for the ESP32's in each robot joint:

3 steppers for small actuators:

1 stepper for large base actuator:

1 stepper for large shoulder actuator:

1 stepper for medium elbow actuator:
