OnePlus 3 Battery Repair Guide Steps:

Warning:

You are performing this repair at your own risk
We claim no responsibility for any damages that might occur

Step 1

Power down your OnePlus 3 phone.

Step 2 (OnePlus 3 Dual Nano-SIM Card Tray)

Remove the dual Nano-SIM card tray.

Step 3 (OnePlus 3 Rear Case)

Remove the following 2 T2 Torx screws from the bottom of the OnePlus 3.

Use the plastic triangle opening tool to release the clips and then pop the OnePlus 3 out of its metal rear enclosure. There is no pesky adhesive, making this procedure a snap.

Step 4 (OnePlus 3 Battery)

Disconnect the OnePlus 3 battery from the logic board.

Remove the following Phillips screw, and then the metal bracket.

Detach and remove the interconnect cable.

Detach the USB-C port cable from the logic board.

Use the exposed clear plastic pull tab to peel the 3000 milliampere-hour (mAh) battery off the adhesive securing it to the OnePlus 3.

* To reassemble your device, follow the steps in reverse order.
