How To Wire A 7-Pin Flat Trailer Plug Quickly And Easily

Wire A 7-Pin Flat Trailer Plug Quickly and Easily doesn’t have to be complicated. Learn how to Wire a 7-Pin Flat Trailer Plug in 10 easy steps. Make sure to watch until the end for extra tips!

Wire A 7-Pin Flat Trailer Plug, most vehicle wiring harness comes with a 7-pin flat plug. Watch how to DIY with this video.

❤️ Enjoyed this video? Subscribe to our channel and hit the notification bell to never miss a new video — and let us know what how-tos you’d like to see next in the comments!

#pinflattrailerplug #wiringharness #wiringproblem
—————————————————————————

Chapters ⌛

0:12 – Easily remove the screw

0:22 – Remove the plug cover

0:38 – Slide the wires through the screw

0:48 – Slide the wires through the rubber dust plug

0:56 – Look how the wires will be attached and what they are used for

1:35 – Insert the exposed wire ends into the correct pins

1:51 – Attached is the retaining clip with the two screws

2:07 – Replace the plug cover

2:15 – Secure the flat plug with the screw

2:25 – Tape over the screw cap

—————————————————————————

Stay connected! 🔗

[zacandmillie]

I'd have finished off with some heat shrink tubing. That tape looked messy

[Watson]

When you are fixing the coloured wires into the plug, number 1 is the first on the left, number 2 is the post next to number 1. NOT way over in the number 5-6 position. I’m taking it you are reading from a list. This doesn’t help a newbie wiring a plug for the first time. Otherwise not bad.5/10.

[anthonycoleman]

Great video, I have to do this tomorrow so real helpful

[SalvoDan]

If your car is wired correctly, and your caravan is wired with Auxiliary instead or Reverse on Pin-2, your caravan will only have Auxiliary power when reversing. If your trailer pulls too much current in this situation, you are likely to fry your vehicles electrics, or worse.
If you’re car wiring is modified to deal with a non-standard trailer, you will cause the reverse lights on a standard-compliant trailer to always be on.
It is best to follow standards and use an Anderson Plug for high-current (50A) Auxiliary or a 12-pin plug for low-current (35A) Auxiliary.
Also note that a 12-pin plug can carry a maximum of 35A Auxiliary so if you try to run a Battery Charger, Fridge, ESC and Hydraulic Brake Pump all at the same time, you will fry your trailers electrics. You are better off using multiple Anderson Plugs if your system has the potential to pull more that 35A in total on Auxiliary.

[RodgSamar]

Hi! Does anyone know how to convert or modify a 4pin plug american std. to a 7 pin flat Australian std?
