High power DRSSTC 40kVA+ running until something breaks!

Показать описание

Same run as last video from different angle. Shot on GoPro hero8

Full bridge cm600ha-24h
Liquid cooled primary
2000A primary current
12.75x48" 22awg
1.14uF mmc
26,800uF bus cap
36x10 spun aluminum toroid
EVR/Philip Slawinski UD+ freewheeling driver
EVR polyphonic midi interrupter / Custom Philip Slawinski long pulse interrupter
All polycarbonate/aluminum enclosure
30kW+ Pulling 180+ amps at 220V
up to 15ms on-times 17%duty cycle
15'+ sparks

Details here:

Smoke at end was caused by inductive heating of hose clamp on primary lead coolant inlet, leading to a melted coolant hose and coolant leak.
